A1/A2 Brass Cable Glands are used with unarmored elastomer and plastic insulated cable. Indoor & Outdoor whenever it is required to provide sealing on cable outer sheath.
The glands provide a single pull resistant seal on the outer sheath of unarmored cable.
| GLAND SIZE | THREAD SIZE | THREAD LENGTH | CABLE RANGE | PART NUMBER | ||
| METRIC | NPT | MIN | MAX | |||
| A1/A2 20S | M20 | 1/2” | 10 | 8,00 | 11,50 | GLA1A2 20S |
| A1/A2 20 | M20 | 1/2” | 10 | 11,00 | 13,50 | GLA1A2 20L |
| A1/A2 25S | M25 | 3/4” | 10 | 13,00 | 16,50 | GLA1A2 25S |
| A1/A2 25 | M25 | 3/4” | 10 | 16,00 | 19,50 | GLA1A2 25L |
| A1/A2 32 | M32 | 1” | 10 | 19,00 | 25,50 | GLA1A2 32L |
| A1/A2 40S | M40 | 1 1/4” | 15 | 23,00 | 29,00 | GLA1A2 40S |
| A1/A2 40 | M40 | 1 1/4” | 15 | 25,00 | 32,00 | GLA1A2 40L |
| A1/A2 50S | M50 | 1 1/2” | 15 | 31,50 | 37,00 | GLA1A2 50S |
| A1/A2 50 | M50 | 2” | 15 | 36,50 | 43,00 | GLA1A2 50L |
| A1/A2 63S | M63 | 2” | 15 | 42,50 | 50,00 | GLA1A2 63S |
| A1/A2 63 | M63 | 2 1/2” | 15 | 49,50 | 55,00 | GLA1A2 63L |
| A1/A2 75S | M75 | 2 1/2” | 15 | 54,50 | 61,00 | GLA1A2 75S |
| A1/A2 75 | M75 | 3” | 15 | 60,50 | 67,00 | GLA1A2 75L |
| A1/A2 90 | M90 | 3” | 20 | 65,00 | 78,00 | GLA1A2 90L |
Material:- Brass
